Intel S3420GPLC - Server Board Motherboard User Manual

Intel® Server Board S3420GP TPS Introduction
Revision 2.4
Intel order number E65697-010
1
1. Introduction
This Technical Product Specification (TPS) provides board specific information detailing the
features, functionality, and high-level architecture of the Intel
®
Server Board S3420GP.
In addition, you can obtain design-level information for specific subsystems by ordering the
External Product Specifications (EPS) or External Design Specifications (EDS) for a given
subsystem. EPS and EDS documents are not publicly available and must be ordered through
your local Intel representative.
1.1 Chapter Outline
This document is divided into the following chapters:
 Chapter 1 – Introduction
 Chapter 2 – Server Board Overview
 Chapter 3 – Functional Architecture
 Chapter 4 – Platform Management
 Chapter 5 – BIOS User Interface
 Chapter 6 – Connector/Header Locations and Pin-outs
 Chapter 7 – Jumpers Blocks
 Chapter 8 – Intel
®
Light-Guided Diagnostics
 Chapter 9 – Design and Environmental Specifications
 Chapter 10 – Regulatory and Certification Information
 Chapter 11 – Regulatory and Certification Information
 Appendix A – Integration and Usage Tips
 Appendix B – Integrated BMC Sensor Tables
 Appendix C – POST Code Diagnostic LED Decoder
 Appendix D – POST Code Errors
 Appendix E – Supported Intel
®
Server Chassis
 Glossary
 Reference Documents
1.2 Server Board Use Disclaimer
Intel Corporation server boards contain a number of high-density VLSI and power delivery
components that need adequate airflow to cool. Intel ensures through its own chassis
development and testing that when Intel server building blocks are used together, the fully
integrated system meets the intended thermal requirements of these components. It is the
responsibility of the system integrator who chooses not to use Intel developed server building
blocks to consult vendor datasheets and operating parameters to determine the amount of
airflow required for their specific application and environmental conditions. Intel Corporation
cannot be held responsible if components fail or the server board does not operate correctly
when used outside any of their published operating or non-operating limits.

Intel S3420GPLC - Server Board Motherboard Specifications

General

Brand	Intel
Model	S3420GPLC - Server Board Motherboard
Category	Server Board
Language	English
