BIOS User Interface Intel® Server Board S3420GP TPS
Revision 2.4
Intel order number E65697-010
56
Setup Item Options Help Text
Comments
Adjacent Cache Line
Prefetch
Enabled
Disabled
[Enabled] - Cache lines are fetched in pairs
(even line + odd line).
[Disabled] - Only the current cache line
required is fetched.
Note: Modifying this setting may affect
system performance.
6.3.2.2.2 Memory Screen
The Memory screen allows the user to view details about the system memory DDR3 DIMMs
installed. This screen also allows the user to open the Configure Memory RAS and Performance
screen.
To access this screen from the Main screen, select Advanced > Memory.
Advanced
Memory Configuration
Total Memory <Total Physical Memory Installed in System>
Effective Memory <Total Effective Memory>
Current Configuration <Independent >
Current Memory Speed <Speed that installed memory is running at.>
►
DIMM Information
DIMM_A1 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_A2 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_A3 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_B1 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_B2 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_B3 Installed/Not Installed/Failed/Disabled/Spare Unit
Figure 22. Setup Utility – Memory Configuration Screen Display
Table 21. Setup Utility – Memory Configuration Screen Fields
Setup Item Comments
Total Memory
Information only. The amount of memory available in the system
in the form of installed DDR3 DIMMs in units of MB or GB.
