Reference Number: 327043-001 25
Intel® Xeon® Processor E5-2600 Product Family Uncore Performance Monitoring
C2_MSR_PMON_BOX_FILTER 0x0D54 32 CBo 2 PMON Filter
Generic Counter Control
C2_MSR_PMON_CTL3 0x0D53 32 CBo 2 PMON Control for Counter 3
C2_MSR_PMON_CTL2 0x0D52 32 CBo 2 PMON Control for Counter 2
C2_MSR_PMON_CTL1 0x0D51 32 CBo 2 PMON Control for Counter 1
C2_MSR_PMON_CTL0 0x0D50 32 CBo 2 PMON Control for Counter 0
Box-Level Control/Status
C2_MSR_PMON_BOX_CTL 0x0D44 32 CBo 2 PMON Box-Wide Control
CBo 3 PMON Registers
Generic Counters
C3_MSR_PMON_CTR3 0x0D79 64 CBo 3 PMON Counter 3
C3_MSR_PMON_CTR2 0x0D78 64 CBo 3 PMON Counter 2
C3_MSR_PMON_CTR1 0x0D77 64 CBo 3 PMON Counter 1
C3_MSR_PMON_CTR0 0x0D76 64 CBo 3 PMON Counter 0
Box-Level Filter
C3_MSR_PMON_BOX_FILTER 0x0D74 32 CBo 3 PMON Filter
Generic Counter Control
C3_MSR_PMON_CTL3 0x0D73 32 CBo 3 PMON Control for Counter 3
C3_MSR_PMON_CTL2 0x0D72 32 CBo 3 PMON Control for Counter 2
C3_MSR_PMON_CTL1 0x0D71 32 CBo 3 PMON Control for Counter 1
C3_MSR_PMON_CTL0 0x0D70 32 CBo 3 PMON Control for Counter 0
Box-Level Control/Status
C3_MSR_PMON_BOX_CTL 0x0D64 32 CBo 3 PMON Box-Wide Control
CBo 4 PMON Registers
Generic Counters
C4_MSR_PMON_CTR3 0x0D99 64 CBo 4 PMON Counter 3
C4_MSR_PMON_CTR2 0x0D98 64 CBo 4 PMON Counter 2
C4_MSR_PMON_CTR1 0x0D97 64 CBo 4 PMON Counter 1
C4_MSR_PMON_CTR0 0x0D96 64 CBo 4 PMON Counter 0
Box-Level Filter
C4_MSR_PMON_BOX_FILTER 0x0D94 32 CBo 4 PMON Filter
Generic Counter Control
C4_MSR_PMON_CTL3 0x0D93 32 CBo 4 PMON Control for Counter 3
C4_MSR_PMON_CTL2 0x0D92 32 CBo 4 PMON Control for Counter 2
C4_MSR_PMON_CTL1 0x0D91 32 CBo 4 PMON Control for Counter 1
C4_MSR_PMON_CTL0 0x0D90 32 CBo 4 PMON Control for Counter 0
Box-Level Control/Status
C4_MSR_PMON_BOX_CTL 0x0D84 32 CBo 4 PMON Box-Wide Control
Table 2-8. CBo Performance Monitoring MSRs (Sheet 2 of 4)
MSR Name
MSR
Address
Size
(bits)
Description
