Intel Xeon E5-2600 Series - Page 26

Intel® Xeon® Processor E5-2600 Product Family Uncore Performance Monitoring
26 Reference Number: 327043-001
CBo 5 PMON Registers
Generic Counters
C5_MSR_PMON_CTR3 0x0DB9 64 CBo 5 PMON Counter 3
C5_MSR_PMON_CTR2 0x0DB8 64 CBo 5 PMON Counter 2
C5_MSR_PMON_CTR1 0x0DB7 64 CBo 5 PMON Counter 1
C5_MSR_PMON_CTR0 0x0DB6 64 CBo 5 PMON Counter 0
Box-Level Filter
C5_MSR_PMON_BOX_FILTER 0x0DB4 32 CBo 5 PMON Filter
Generic Counter Control
C5_MSR_PMON_CTL3 0x0DB3 32 CBo 5 PMON Control for Counter 3
C5_MSR_PMON_CTL2 0x0DB2 32 CBo 5 PMON Control for Counter 2
C5_MSR_PMON_CTL1 0x0DB1 32 CBo 5 PMON Control for Counter 1
C5_MSR_PMON_CTL0 0x0DB0 32 CBo 5 PMON Control for Counter 0
Box-Level Control/Status
C5_MSR_PMON_BOX_CTL 0x0DA4 32 CBo 5 PMON Box-Wide Control
CBo 6 PMON Registers
Generic Counters
C6_MSR_PMON_CTR3 0x0DD9 64 CBo 6 PMON Counter 3
C6_MSR_PMON_CTR2 0x0DD8 64 CBo 6 PMON Counter 2
C6_MSR_PMON_CTR1 0x0DD7 64 CBo 6 PMON Counter 1
C6_MSR_PMON_CTR0 0x0DD6 64 CBo 6 PMON Counter 0
Box-Level Filter
C6_MSR_PMON_BOX_FILTER 0x0DD4 32 CBo 6 PMON Filter
Generic Counter Control
C6_MSR_PMON_CTL3 0x0DD3 32 CBo 6 PMON Control for Counter 3
C6_MSR_PMON_CTL2 0x0DD2 32 CBo 6 PMON Control for Counter 2
C6_MSR_PMON_CTL1 0x0DD1 32 CBo 6 PMON Control for Counter 1
C6_MSR_PMON_CTL0 0x0DD0 32 CBo 6 PMON Control for Counter 0
Box-Level Control/Status
C6_MSR_PMON_BOX_CTL 0x0DC4 32 CBo 6 PMON Box-Wide Control
CBo 7 PMON Registers
Generic Counters
C7_MSR_PMON_CTR3 0x0DF9 64 CBo 7 PMON Counter 3
C7_MSR_PMON_CTR2 0x0DF8 64 CBo 7 PMON Counter 2
C7_MSR_PMON_CTR1 0x0DF7 64 CBo 7 PMON Counter 1
C7_MSR_PMON_CTR0 0x0DF6 64 CBo 7 PMON Counter 0
Box-Level Filter
C7_MSR_PMON_BOX_FILTER 0x0DF4 32 CBo 7 PMON Filter
Generic Counter Control
Table 2-8. CBo Performance Monitoring MSRs (Sheet 3 of 4)
MSR Name
MSR
Address
Size
(bits)
Description
