10 i3/i4 Satellite Antenna System – Install and User Manual
Installation and Fixation of antenna
The method of installation and fixation of antenna may be diverse with vessel
design but the following procedures are applicable in most situations and will
result in a secure and effective installation.
Confirmation of size and installation of power tower
y Confirm the height and diameter of the bottom surface of the
antenna before installing it.
y The space must be sufficient for installing the antenna unit
considering the height and diameter of the antenna.
y The height and the diameter of the bottom surface of the antenna
are as shown in the following drawing. If possible, install power
tower where antenna is to be installed.
Ø50 (19.7”)
54 (21.2”)
Unit : cm (inch)
Intellian i4
