Operation Using PC Controller Program 51
OPERATION USING PC Controller Program
Introduction
GUI Software of Intellian i3/i4 has been coded for the user to easily set up the
antenna by using the user’s personal computer. Using the GUI program enables
the user to easily monitor and modify the information of antenna, satellite and
GPS. Additionally, the detail diagnostic method of the antenna is provided by the
GUI program.
To start this GUI program,
1. Connect one end of PC serial cable to the serial port on the computer.
2. Connect the other end of the PC serial cable to the “PC Interface” on the
rear of ACU.
3. Execute GUI program by inserting the CD-ROM supplied into the CD-ROM
drive of the computer.
4. After turning on the power of the ACU, if the blue status circle does not
change to ‘Search’ or ‘Tracking’ from ‘Initialize’, then you have to change
the “PC Interface” terminal of ACU for PC program use rather than GPS
use.
