Intellian i3 Install And User Manual

Installation 15
Installing the ACU
ACU dimensions
5.38 (2.1”)
21.68(8.5”)
20.8 (8.2”)
22.8 (9”)
17.8 (7”)
5.5(2.2”)
13(5.1”)
18.5(7.3”)
Unit : cm (inch)
Installation Site
The ACU should be installed below decks, in a place of :
y Dry, cool, and ventilated.
y Easy accessible from your main TV viewing area.
