Installation 21
Target Satellite Setting
You can select the target satellite to receive satellite signal. If the target
satellite is not on the list you have to register the target satellite.
GPS Setting
You can input the GPS information through the ACU or the PC Program. To
setting the GPS information, the antenna system has to be in ‘SET UP mode’.
For detailed instructions, please refer to page 39; ‘Setting the GPS’, and page
59; ‘Set Antenna GPS and find Antenna Angle’.
Satellite registration
You can register the target satellite through the ACU or the PC Program. To
register the target satellite, the antenna system has to be in ‘SET UP mode’
and the required information are, Satellite name, Satellite Longitude, Method
of Satellite identification, Frequency of each of the Band, Symbol Rate,
Network ID, Power Change method. For detailed instructions, please refer to
page 32; ‘Edit Satellite Information’, page 54; ‘Set Satellite Information’, and
page 60; ‘Set Tracking Information of Satellite’.
Satellite Pair Selection
You can select the Satellite pair from the list through the ACU or the program.
You can easily select the target satellite from the satellite pair. For detailed
instructions please refer to page 30; ‘Setting the Satellite pair’, page 54; ‘Set
Satellite Information’.
Target Satellite Selection
Choose the target satellite from the Satellite Pair. When selecting through
the ACU, you have to press the left button to select the target satellite while
the antenna system is in either ‘Searching Mode’ or ‘Tracking Mode’. When
using the PC program you can select either satellite ‘A’ or satellite ‘B’ from
‘Tracking Satellite’ at anytime.
