Introduction 3
Basic System Configuration of Intellian i3/i4
In order to work your satellite TV system properly, the system will have to
connect with all of the provided components properly as shown in the figure
below (Refer to next chapter ‘Installation’ of this manual for the more detail
connection method). Separate purchase of a satellite receiver and a TV is
required.
NMEA GPS
TV (Not Supplied)
PC( No t Sup p lied)
Satellite Receiver (Not Supplied)
DC Po wer on Vessel
(DC-10.8-15.6V)
Antenna Control Unit
TV (Not Supplied)
Satellite Receiver (Not Supplied)
