24 i3/i4 Satellite Antenna System – Install and User Manual
Operation Using the ACU
ACU Soft Keys
BACK
ENTER
POWER
Press to select
On-screen option
Normal Mode
Start Up
With the system installed and power applied, the ACU screen will show the
following sequence:
INITIALIZE ACU
INTELLIAN I3
SEARCH A: DTV101
B:DTV119 SETUP
1.Communication is being established between the
antenna and the ACU. The ACU initialized.
INITIALIZE ANTENNA
INTELLIAN I3
TRACKING A:DTV101
B:DTV119 SETUP
2. The antenna is initialized.
3. The antenna is searching for Satellite A.
4. The anten n a h as located the satellite and is now
tracking.
