Installation 5
Antenna Control Unit (ACU)
Antenna Control Unit (ACU) provides the power to the antenna and controls
the various settings of the antenna. Additionally, VFD (Vacuum Fluorescent
Display) allows for you to access the ACU in the dark.
The functions of the ACU are as follows:
y Provide power for the Antenna Unit
y Monitor the antenna status
y Change the target satellite
y Set up the user environment
y Set the current GPS information
y Set satellite information
y Move antenna manually
y Perform self-diagnosis of the antenna
y Set up the interface with PC
Front
Rear
