D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 4
Yellow drill guide (supplied with the product)
½”/1.27 cm thick black washers (supplied with the product)
High strength black oxide steel threaded rod 3/8” -16 thread
size, 5” / 12.7 cm long (supplied with the product)
Allan Key (supplied with the product)
Masonry drill for concrete (supplied with the product)
Booth observation camera mount parts (supplied with the
product)
Battery powered drill with Phillips bit
Hammer drill with SDS Plus chuck (A SDS Plus ½” / 1.27 cm
inch masonry drill bit is supplied)
Small battery powered screwdrivers (flat blade)
Small head Phillips screwdriver (supplied with the product)
Small Shop-Vac (Vacuum cleaner with hose adapter)
