Intergraph TDZ 2000 GL2 - Connecting System Peripherals

3
CAUTION Do not move the system without first shutting down the system and turning off the power, or
damage to internal components may result.
Setting Up the System
Before you connect any cables to the back of the system, note the connector locations in the
following illustration.
AC power
connector
AC voltage switch
115/230 V
Mouse
Ke
y
board
USB
Parallel
COM
Line out
Line in
Mic in
MIDI/game
Video out
See the System Reference for technical details on each port.
