Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 121
6.2.n.2 Output location
The Output location is a read-only field that is a physical identification of the
output in a format “<device> <y>.<z>”, where <device> can be a panel, an
expander, or a keypad, <y> is the device number, and <z> is a device output
number.
6.2.n.3 Invert output
The Invert output option determines if the output is inverted.
6.2.n.4 Start filter
00>Not used
01 Internal Sire
Use the Start filter menu to specify a condition filter that activates the output. The
output behaviour depends on the output activation mode, described in “6.2.n.6
Mode” below.
6.2.n.5 Stop filter
00>Not used
01 Internal Sire
Use the Stop filter menu to specify an optional condition filter that deactivates the
output.
6.2.n.6 Mode
The following modes are available:
• Follow: The output state is equal to the start condition filter state, unless the
stop conditional filter becomes valid.
The start of the output activation depends on the delay programmed in
“6.2.n.7.1 Delay time” on page 123.
If the delay is programmed to 0, the output activates immediately. Otherwise,
the output activates only after the start condition filter has been active for the
time programmed.
When the stop condition filter activates, the output immediately becomes
passive.
• Pulsed: Switching the start condition filter on causes starting the delay timer
set in “6.2.n.7.1 Delay time” on page 123. After the time passes, the output
activates for a time defined in “6.2.n.7.2 Active time” on page 123, and then it
switches off.
