Appendix A: Door controller events
CDC4 Door Controller Installation and Programming Manual 119
Name
Description
Input
Output
Controller DGP offline
DGP on Intelligent Controller sub-Bus is offline.
Yes
No
Controller battery test
active [1]
The battery test on this Controller is running (1 event)
Yes
No
Controller battery test
fail [1]
The battery test failed on this Controller (1 event)
Yes
No
Controller battery low
[1]
Low battery condition exists on the Controller
(1 event)
Yes
No
Controller fuse fail [1]
Fuse Fail condition exists on the Controller (1 event)
Yes
No
Controller mains fail [1]
Mains fail condition exists on the Controller (1 event)
Yes
No
Controller offline [1]
Controller is not communicating with the Challenger
(1 event)
Yes
No
Controller siren active
[1]
The siren output (16th output) is active (1 event)
Yes
No
Controller siren fail [1]
Siren fail (siren tamper) condition exists on this
Controller (1 event)
Yes
No
Controller tamper [1]
Cabinet tamper condition exists on this Controller
(1 event)
Yes
No
DGP output
System output assigned to this DGP is active
(16 events, 1 per output). The first 16 outputs on DGP
can also be activated by physical output function.
Yes
Yes
Input
Input on this DGP is active (16 events, 1 per input)
Yes
Yes
Physical output
Output connected to this DGP is active (255 events,
1 per output). If the physical output is numbered
higher than the first 16 in the DGP, then it can only be
activated by door macro.
Yes
Yes
RAS Offline
RAS on Intelligent Controller sub-Bus is offline
(16 events, 1 per RAS address)
Yes
No
Region limit [1]
When the number of people in any region reaches the
present limit (255 events, 1 per region)
Yes
No
[1] Denotes the event is currently not enabled.
Table 12: Macro event range for doors
Name
Input- I,
Output –O,
Both – I/O
D1
D2
D3
D4
D5
D6
D7
D8
DOOR OPEN
I/O
1
2
3
4
5
6
7
8
DOOR UNLOCKED
I/O
9
10
11
12
13
14
15
16
DOOR LOCK
O
17
18
19
20
21
22
23
24
DOOR OVERRIDE
I/O
25
26
27
28
29
30
31
32
DOOR OVERRIDE INHIBIT
I/O
33
34
35
36
37
38
39
40
DOOR DISABLED
I/O
41
42
43
44
45
46
47
48
DOOR ENABLED
O
49
50
51
52
53
54
55
56
DOOR READER DISABLED [4]
I/O
57
58
59
60
61
62
63
64
