CDC4 Door Controller Installation and Programming Manual 117
Appendix A
Door controller events
For Door events, see Table 10 below. For other events, see Table 11 on page
118.
For macro event ranges, refer to the following tables:
• Table 12 on page 119 for doors
• Table 13 on page 121 for areas
• Table 14 on page 121 for data buses
Table 10: Door macro event descriptions
Name
Description
Input
Output
Door access denied
Door access has not been allowed
Yes
No
Door access granted
Door access has been allowed
Yes
No
Door access granted 1st
badge
Door access has been granted when badged once
Yes
No
Door access granted 2nd
badge
Door access has been granted when badged twice
Yes
No
Door access granted 3rd
badge
Door access has been granted when badged three
times
Yes
No
Door access granted in
button
Door access has been granted and IN button
pressed
Yes
No
Door access granted out
button
Door access has been granted and OUT button
pressed
Yes
No
Door access granted
traced
Door access has been granted to a user with trace
On
Yes
No
Door anti-passback [2]
Anti-passback is active
Yes
No
Door area secure
Area assigned to door is secure
Yes
Yes
Door buzzer [3]
Buzzer output is active
Yes
Yes
Door disabled
Door is disabled completely (from keypad or
computer)
Yes
Yes
Door two-badge inside [2]
Two-badge access is required at the "IN” reader
Yes
Yes
Door two-badge outside
[2]
Two-badge access is required at the “OUT” reader
Yes
Yes
