Appendix B: CDC4 defaults
124 CDC4 Door Controller Installation and Programming Manual
Table 16: Hardware Options: Default Input/Output number assignments
Door number
Location
Device number
Lock output 1
1
st
Door
On-board
1
2
nd
Door
On-board
2
3
rd
Door
On-board
3
4
th
Door
On-board
4
5
th
Door
On-board
NONE
6
th
Door
On-board
NONE
7
th
Door
On-board
NONE
8
th
Door
On-board
NONE
Door input 1
1
st
Door
On-board
1
2
nd
Door
On-board
3
3
rd
Door
On-board
5
4
th
Door
On-board
7
5
th
Door
On-board
NONE
6
th
Door
On-board
NONE
7
th
Door
On-board
NONE
8
th
Door
On-board
NONE
RTE input
1
st
Door
On-board
2
2
nd
Door
On-board
4
3
rd
Door
On-board
6
4
th
Door
On-board
8
5
th
Door
On-board
NONE
6
th
Door
On-board
NONE
7
th
Door
On-board
NONE
8
th
Door
On-board
NONE
