107Intermec EasyCoder 501 – Service Manual Ed. 7
Chapter 13 Memory Card Adapter
13.1 Description, cont.
Bus Driver Board; Components Diagrams
Bus Driver Board as fi tted on the CPU Board
Bus Driver Board 1-971712-25; Components
P1
P1 MOUNTED ON SOLDERING SIDE
P2
D1
971712.ØØ
C3
IC3 IC4
IC2
IC1
C2
C1
To Next Page
