Intermec EasyCoder PC4 User Manual

 

O
I
Power Connection
1 Place the printer in a suitable location that allows easy access to
printed labels and preferably also easy reload of media and transfer
ribbon. e printer should only be operated while resting on a hori-
zontal surface, like a table or similar.
e printer and power supply unit must never be operated
in a location where they can get wet. Personal injury could
result! Only use with power supply adapter Intermec SPN-
470-24 P/N 1-092515-XX.
2 Place the power supply adapter in a suitable location between the
printer and an electrical outlet, for example on the floor. e power
supply adapter can be used for 100 to 240 VAC, 50 to 60 Hz. e
configuration of the power cord plug differs according to national
standards.
3 Check that the printer’s On/Off switch at the back is off (O).
4 First, fit the round connector into the power receptacle on the
printer's rear plate. en connect the power cord between the power
supply adapter and an AC wall socket.
5 e power can be switched on/off by means of the On/Off switch
situated at the back of the printer. e indicator lamp on the printer
lights green, red, or orange to indicate that the power is on. (It also
indicates various conditions, see Chapter 3.)
On/Off switch
Power receptacle
Power cord
Power supply
adapter
Low voltage
cable
Indicator lamp

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
