Intermec EasyCoder PC4 User Manual

 

Software Installation
If you intend to use the USB interface, you must start by installing the
Intermec USB printer driver, which is included on the CD-ROM that
comes with the printer.
If you run your EasyCoder PC4 from a PC under Windows 98/Me, or
Windows NT 4.0/W2000/XP, you may want to install the Intermec
InterDriver and the Intermec LabelShop START found on the CD-
ROM that comes with the printer.
If you use any other operating system than Windows, you will need
to use the ESim protocol described in the Intermec ESim v6.XX, Pro-
grammer’s Reference Manual. (Intermec ESim also supports Windows.)
Updates and installation instructions are available at the Intermec home
page http://www.intermec.com.
Note: ere are different firmware for the 203.2 dpi (8 dots/
mm) and the 300 dpi (11.81 dots/mm) versions.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
