Intermec EasyCoder PC4 User Manual

 

RS-232 Serial Interface
Printer connector: DB-9pin female RS-232 connector.
Printer EasyCoder PC4 Host
Signal DB-9 Signal DB-9 DB-25 Signal
1 +5V 500 mA
1
1
RXD 2 TXD 2 3 RXD
TXD 3 RXD 3 2 TXD
DTR 4 – 4 20 DTR
GND 5 GND 5 7 GND
DSR 6 RDY 6 6 DSR
RTS 7 – 7 4 RTS
CTS 8 RDY 8 5 CTS
9 – 9
1
/.e combined load on the external +5V on both the parallel and the
serial port must not exceed a total of 500 mA.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
