Intermec EasyCoder PC4 User Manual

 

Parallel Interface
Handshake: DSTB to printer and BUSY to host.
Printer connector: 36-pin female Centronics connector.
Pin Signal Name Transmitter
1 -Strobe Host
2–9 Data 0–7 Host
10–11 Busy Printer
12 Paper empty Printer
13 Select Printer
14–15 Not connected
16 Signal ground
17 Chassis ground
18 + 5V DC Max. 500 mA
1
19–30 Signal ground
31 -Init
32 -Fault Printer
33 Signal ground
34–36 Selectin
1
/.e combined load on the external +5V on both the parallel and the
serial port must not exceed a total of 500 mA.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
