Label Taken Sensor
e built-in Label Taken Sensor (LTS) can be enabled to hold the
printing until the previous label (or similar) has been removed from the
printer's outfeed slot. As long as the sensor detects a label, the printer
will be BUSY and cannot receive data from host.
If using the ESim protocol described in the ESim v6.XX, Programmer’s
Reference Manual, note the following:
• e LTS can be enabled/disabled manually using the switch next to
the sensor (see below) or in the ESim protocol by an O command.
• When switching between peel-off, tear-off operation and cut-off
operation, the media feed must be readjusted by means of a j com-
mand.
e Intermec InterDriver provides options for selecting the following
modes of operation without any j or O commands having to be entered
by the operator:
• Tear-off
• Peel-off with LTS enabled
• Peel-off with LTS disabled
If the printer runs out of media while printing, do not
switch off the power during reload, or data will be lost!
OFF
ON
The Label Taken Sensor can be enabled (on) or disabled (off) using a manual switch
inside the peel-off mechansim.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
