Intermec EasyCoder PC4 User Manual

 

Media Roll Size
Core
Diameter (A): 25.4 or 38.1 mm (1.0 or 1.5 inches)
Max. width: 118 mm (4.65 inches)
Roll
Max. diameter (B): 125 mm (5 inches)
Max. media width (C): 116 mm (4.57 inches)
Min. media width (C): 25 mm (1 inches)
Max. media thickness: 0.15 mm (0.006 inches)
Min. media thickness: 0.06 mm (0.003 inches)
All types of media should normally be wound with the printable side
facing outwards and unroll from the top of the roll. However tags and
continuous strip can optionally be wound with the printable sidefacing
inwards and unroll from the bottom of the roll as long as they are not
used for cut-off operation.
Protect the media against sand, grit, and other hard par-
ticles during printing and storage. Keep the cover closed.
Even very small foreign particles may cause severe harm to
the delicate printhead.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
