Intermec EasyCoder PC4 User Manual

 

Computer Connection
All EasyCoder PC4 models are fitted with a 36pin female Centronics
connector for the parallel interface port, a DB-9pin female connector for
the RS-232 serial interface port, and a USB connector. ough all ports
can be connected simultaneously, only one should be used at a time.
Centronics Parallel Interface
If you intend to use the Intermec InterDriver or any version of Intermec
LabelShop, connect the parallel communication cable delivered between
the printer’s Centronics interface connector and the parallel port of your
PC (LPT1).
e parallel interface can also be used for programming the printer using
the ESim protocol described in the Intermec ESim v6.XX, Programmer’s
Reference Manual. However, prompts and other information from printer
to host cannot be transmitted, since the parallel interface is one-way
(host-to-printer) only.
O
I
RS-232CentronicsUSB

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
