Intermec EasyCoder PC4 User Manual

 

Green (solid) Media loaded
Ribbon loaded (TTR only)
Green (flashing) Receiving data
(T
est Mode only)
Red (solid) Out of media
Out of ribbon (TTR only)
Printer reset
Red (short flashes) Upgrading firmware
Red (long flashes) Media jam in cutter
Ov
erheated printhead or
stepper moto
r
Orange
Error condition detected or
Bootloader active
Dark
Po
wer off
Color Meaning
Indicator Lamp
When the power to the printer is switched on, the indicator lamp will
glow green if the printer is loaded with media and—in case of thermal
transfer printing—ribbon.
If the printer is out of media and/or ribbon, the indicator lamp will glow
red.
Any error condition, such as label stop sensor problems, media jams, or
software errors, will be indicated by the lamp changing to orange, except
for media jams in the optional cutter, which are indicated by long red
flashes.
If the indicator lamp fails to work as described above, please refer to
Chapter 5 “Troubleshooting”.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
