Tags and Strip with Black Marks
← a → Tag or strip width:
Maximum: 116.0 mm (4.57 inches)
Minimum: 25.0 mm (1.00 inches)
← b → Tag length:
Minimum: 6.35 mm (0.25 inches)
← c → Detection slot width:
← c → Black mark width:
Minimum: 28 mm (1.10 inches)
← d → Black mark height:
Maximum: 10 mm (0.39 inches)
Minimum: 3 mm 0.12 inches)
e black mark sensor is offset 10 mm (0.394 inches) to the right of the center of the
media path.
Max. reflectance 5% at 940 nanometer. Carbon black.
