Intermec EasyCoder PC4 User Manual

 
Declaration of Conformity (CE)
We,
Intermec Printer AB
Flöjelbergsgatan 1C
Box 123
S-431 22 Mölndal
Sweden
declare under our sole responsibility
1
that the product
EasyCoder PC4
to which this declaration relates
is in conformity with the following standards
Safety:
EN 60 950
EMC:
Based upon EN 50081-2 Generic Emissions Standard
Based upon EN 50 082-1 Generic Immunity Standard
following the provisions of Directives
89/336/EEC and 73/23/EEC
Mölndal 2004-10-08
...................................................................
Per-Ove Jacobsson
Site Manager
1
/. Intermec assumes no responsibility regarding the CE Directive if the
printer is handled, modified, or installed in other manners than those described
inthe manuals.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
