Intermec EasyCoder PD4—User’s Guide 7
Chapter 2—Installation
Front View
At the front of the printer are the display window, the control lamps, and
the control keys. ese features allow the operator to control and set up
the printer manually as described later in this chapter.
e printed labels, tickets, or tags are presented at the front of the print
mechanism. e front cover can be removed for loading of labels at peel-
off (self-strip) operation and for installation of a cutter (options).
Side door with
inspection window
Control lamps
LCD display
(some models
only)
Control keys
Front cover
