Intermec EasyCoder PD4 User Manual

54 Intermec EasyCoder PD4—User’s Guide
Chapter 8—Maintaining the Printer
External Cleaning
Always unplug the power cord before cleaning the printer.
If using the printer in an industrial environment, where
the premises may be cleaned using a water hose or steam,
move the printer to another room or cover it carefully with
a plastic sheet and make absolutely sure that the power cord
is unplugged.
Clean the external surfaces using a soft cloth, possibly slightly moisten
with water or a mild detergent.
Stuck labels should be peeled away using your fingers only. If necessary,
dissolve the adhesive using isopropyl alcohol first.
Isopropyl alcohol [(CH
3
)
2
CHOH; CAS 67-63-0] is a highly
flammable, moderately toxic, and mildly irritating sub
-
stance.
