60 Intermec EasyCoder PD4—User’s Guide
Chapter 9—Adjustments
Printhead Dot Line Position Adjustment
When using thick or stiff media, the printhead needs to be moved for-
ward so the dot line becomes exactly aligned with the top of the platen
roller. Obviously, the platen roller and printhead must also be completely
in parallel.
To perform this adjustment, follow the steps below:
1 Open the top cover.
2 Remove the ribbon.
3 Important step! Use a straight-slot screwdriver to turn the two screws
at the top of the printhead bracket counterclockwise a single turn.
4 Lift the printhead by pulling out the printhead lever and flipping it
counterclockwise a quarter of a turn.
