Intermec EasyCoder PD4—User’s Guide 81
Appendix B—Media Specifications
Tickets with Black Mark
⇐ a ⇒ Media Width
Maximum: 118.0 mm (4.65 inches)
Minimum: 25.0 mm (1.00 inches)
⇐ b ⇒ Copy Length
Maximum:
8 dots/mm (203.2 dpi) 1270 mm (50 inches)
11.81 dots/mm (300 dpi) 558.8 mm (22 inches)
Minimum:
8 dots/mm (203.2 dpi) 10 mm (0.39) inches)
11.81 dots/mm (300 dpi) 10 mm (0.39) inches)
⇐ c ⇒ Detection Position
Variable: 0 to 57 mm (0 to 2.24 inches)
⇐ d ⇒ Black Mark Width
e detectable width of the black mark should be at least 5.0 mm (0.2
inches) on either side of the LSS detection point.
⇐ e ⇒ Black Mark Length
Maximum: 25 mm (0.98 inches)
Common: 5 mm (0.2 inches)
Minimum: 3 mm (0.12 inches)
⇐ f ⇒ Black Mark Y-Position
It is recommended that you place the black mark as close to the front
edge of the ticket as possible and use a negative Stop Adjust value to
control the media feed, so the tickets can be properly torn off.
Paper Type Setup
• Black mark
Note: Preprint that may interfere with the detection of the
black mark should be avoided.
Note: e black mark should be non-reflective carbon black on
a whitish background. Do not allow any perforations to break
the edge of the media as this may cause the media to split and
jam the printer.
