40 Intermec EasyCoder PD4—User’s Guide
Chapter 6—Options
Stripper and Internal Rewinder
Installation Instructions
1 Remove the screw that holds the front cover. Remove the front cover.
2 Open the side door and remove the rewinder option cover plate,
which is held by two Phillips screws.
Cover plate
Front cover
Screw
