86 Intermec EasyCoder PD4—User’s Guide
Appendix C—Interface
Parallel Interface
Handshake: DSTB connects to the printer, BUSY connects to the
host
Interface cable: Parallel cable compatible to IBM PC
Pinout Description
Pin Function Transmitter Comment
1 /Strobe host
2-9 Data 0-7 host
10 /Acknowledge printer
11 Busy printer
12 /Paper empty printer
13 /Select printer
14-16 Not connected
17 Chassis ground
18 External +5V DC Max 500mA, permanently
enabled
19-30 Signal ground
31 Not connected
32 /ERROR printer
33 Signal ground
34-36 Not connected
