Chapter 4 — Enabling and Configuring Symbologies
78 SR60 Scanner Programmer’s Reference Manual
\
2 Scan the SET bar code.
3 Scan the Set Minimum Label Length bar code.
4 Using the Digits bar codes on page 79, scan the digits to set
the minimum label length you identified in Step 1.
5 Scan the END bar code.
Note: For this symbology, the scanner decodes up to 48
characters, but the actual length read varies depending upon
interface type, bar code physical size, and print quality. Code
39 bar codes containing one or more full ASCII characters can
also limit the amount of characters that are decoded; in these
circumstances, the scanner decodes at least 24 data characters.
Note: To set a label length less than ten, you must scan a zero
digit first and then the length digit (such as 04, 06, or 08).
Minimum Label Length
SET------------------------------------
Set Minimum
Label Length ---------
END------------------------------------
To Next Page
