Interroll DL Series - Electrical Data for DL Series Asynchronous 3-Phase; DL 0080 Asynchronous 3-Phase

Version 1.2 (08/2022) en
Translation of original operating instructions 21 of 64
Product information of DL series asynchronous 3-phase
1 Connection diagram number 17 UKCA mark
2 Rated power 18 UL mark
3 Number of poles + operating mode 19 International Electrotechnical Commission: Standard
for drum motors
4 Rated frequency
1)
20 Drum tube diameter
5 Rated voltage at rated frequency 21 Drum width
6 Rated current at rated frequency 22 Weight
7 (Rated voltage)
1)
23 Insulation class and protection rate
8 (Rated current)
1)
24 Circumferential speed of drum tube
1)
12 Serial number 25 Manufactured week/year/country
13 Order number + item 26 Oil type and quantity
14 Customer item number 27 Type and design
15 Manufacturer's address 28 QR code
16 CE mark
1)
The value depends on the voltage used. All values in parentheses refer to the rated voltage in parentheses.
5.2 Electrical data for DL series asynchronous 3-phase
Abbreviations see page 56.
5.2.1 DL 0080 asynchronous 3-phase
P
N
n
P
n
N
f
N
U
N
I
N
cos
φ
η
J
R
I
S
/I
N
M
S
/
M
N
M
B
/
M
N
M
P
/
M
N
M
N
R
M
U
SH
delta
U
SH
star
U
r
W min
-1
Hz V A kg x
cm
2
Nm Ω VDC V DC µF
40 4 1320 50 230 0,76 0,65 0,20 0,89 1,66 2,88 2,88 2,88 0,29 156,5 38,7
–
10
40 4 1584 60 230 0,75 0,65 0,21 0,89 1,58 2,88 2,88 2,88 0,24 156,5 38,1
– –
40 4 1320 50 400 0,45 0,65 0,20 0,89 1,70 2,88 2,88 2,88 0,29 156,5
–
68,7 10
40 4 1584 60 460 0,41 0,65 0,19 0,89 2,14 2,88 2,88 2,88 0,24 156,5
–
62,6
–
50 2 2800 50 230 0,46 0,73 0,40 0,87 3,89 3,82 3,82 3,82 0,17 74,2
– – –
50 2 3360 60 230 0,45 0,73 0,40 0,87 3,78 3,29 3,29 3,29 0,14 74,2
– – –
50 2 2750 50 400 0,22 0,71 0,46 1 4,35 2,35 2,35 2,35 0,17 342
–
80,1
–
60 4 1320 50 230 0,79 0,65 0,30 0,89 1,66 1,6 1,6 1,6 0,43 156,5 40
–
11
60 4 1584 60 230 0,76 0,65 0,31 0,89 1,58 1,6 1,6 1,6 0,36 156,5 39
–
13
60 4 1320 50 400 0,46 0,65 0,28 0,89 1,70 1,6 1,6 1,6 0,43 156,5
–
70 11
