Assembly and installation
8 Assembly and installation
8.1 Warning notices concerning the installation
CAUTION
otating parts and inadvertent startup of the motor!
Riskofcrushingforngers.
¾ Do not reach into areas between drum motor and conveyor belts or roller chains.
¾ Installaprotectiondevice(suchasaguardplate)topreventngersfromgettingtrappedinthechainbelts
or roller chains.
¾ Install an appropriate warning on the conveyor.
NOTICE
Risk of damage leading to failure or shortened service life of the drum motor!
¾ Do not drop or mishandle the drum motor to avoid internal damages.
¾ Prior to the installation, inspect each drum motor for damage after storage.
¾ Do not hold, carry, or support the drum motor by the wires or terminal boxes extending out of the mounting
shaft to avoid damage to the internal parts and seals.
¾ Do not twist the motor cable.
¾ Do not overtension the belt.
8.2 Installing the drum motor
8.2.1 Positioning the drum motor
Ensurethatthedataonthetypeplatearecorrect,andmatchtheorderedandconrmedproduct.
Aspecialdesignmustbeusedtoinstallthedrummotorinnon-horizontalapplications.Theexactversion
mustbespeciedwhenordering.Incaseofdoubt,contactInterroll.
Thedrummotormustbemountedhorizontallywithaclearanceof+/–5°(drummotorDL0113:+/–2°),
unlessspecieddierentlyintheorderconrmation.
