Interroll DL Series - Connection Diagrams of DM Series Asynchronous 3-Phase; Cable Connections

Version 1.2 (08/2022) en
Translation of original operating instructions 23 of 64
Product information of DL series asynchronous 3-phase
P
N
n
P
n
N
f
N
U
N
I
N
cos
φ
η
J
R
I
S
/I
N
M
S
/
M
N
M
B
/
M
N
M
P
/
M
N
M
N
R
M
U
SH
delta
U
SH
star
U
r
W min
-1
Hz V A kg x
cm
2
Nm Ω VDC V DC µF
180 4 1355 50 400 0,62 0,76 0,55 4 4,42 3,6 3,79 3,6 1,27 45,5 – 32,2 15
180 4 1626 60 230 1,08 0,76 0,55 4 4,59 3,44 3,27 3,44 1,06 45,5 18,7 – 12
180 4 1626 60 460 0,62 0,76 0,48 4 5,22 4,76 4,54 4,76 1,06 45,5 – 32,2 11
330 2 2800 50 230 1,74 0,76 0,63 3,3 4,5 3,57 3,57 2,62 1,13 21,5 14,2 – –
330 2 3360 60 230 1,43 0,76 0,76 3,3 4,5 3,2 3,2 3,2 0,94 21,5 11,7 – –
330 2 2800 50 400 0,93 0,76 0,67 3,3 4,5 3,57 3,57 2,62 1,13 21,5 – 22,8 –
330 2 3360 60 460 0,83 0,76 0,66 4,5 4,5 3,2 3,2 3,2 0,94 21,5 – 20,3 –
5.3 Connection diagrams of DM series asynchronous 3-phase
These operating instructions list only standard connection diagrams. For other connection types, the connection
diagram is supplied separately with the drum motor.
Abbreviations see page 56.
5.3.1 Cable connections
3-phase, 6-core cable, winding for 1 voltage, delta or star connection (internally connected)
Delta connection: Low voltage Star connection: High voltage
