Maintenance and cleaning
10.5.1 Cleaning the drum motor with pressure washer
Only drum motors made of stainless steel with IP66 seals are suitable for cleaning with a pressure washer.
NOTICE
Seal not tight due to excessive pressure!
¾ Donotholdthenozzleinapositiondirectedontotheshaftsealwhencleaningthelabyrinthortheseal.
¾ Movethenozzlecontinuouslyandevenlyovertheentiredrummotor.
Observe the following when using a pressure washer:
• Ensurethatthedistancebetweenthehigh-pressurenozzleandthedrummotorisatleast30cm.
• Observe the maximum pressure from the table below.
• Performthepressurewashingofthedrummotoronlyduringrunningoperation;otherwise,watercouldenterorthe
seals could be damaged.
The maximum value for cleaning temperature and pressure depends on the seal type.
Seal type Max. temperature Max. water pressure Comment
NBR - IP66 80 °C 50 bar For general use
NBR IP66 seal that can be
re-lubricated
60 °C 50 bar DL series for wet and
food-grade applications
• Re-lubricate DL series
motors after cleaning
