Assembly and installation
8.5 Drum coating
A drum coating (e.g. rubber coating) that was applied retroactively can cause the drum motor to overheat. For some
drum motors, there may be restrictions concerning the thickness of the drum coating.
To avoid a thermal overload, the required output should be multiplied with 1,2.
Please contact Interroll concerning the type and maximum thickness of a drum coating if you want to apply
one.
8.6 Sprockets
Tooperatelinkbeltswithsprocketsrequiresthatasucientnumberofsprocketsareattachedtothedrumshellin
ordertosupportthebeltandtocorrectlytransfertheforce.Sprocketsthatengagewiththebeltmusthaveaoating
ttopreventthemfrominterferingwiththethermalexpansionofthebelt.Onlyonesprocketmaybeaxedforbelt
guidance;asanalternative,thebeltmayalsobeguidedatthesides.
Forabeltguidancewithxedsprocket,thenumberofsprocketsshouldbeoddsothatthexedsprocketcanbe
arranged in the center. At least one sprocket should be used for every 100 mm belt width. The minimum number of
sprockets is 3.
The force is transferred using a key steel welded onto the drum tube. In general, this key steel is 50 mm shorter than
the tube length (SL).
NOTICE
Damage to the belt!
¾ Donotuseaxedsprockettogetherwithsideguides.
8.7 Warning notices concerning the electrical installation
WARNING
Electrocution due to improper installation!
¾ Allelectricalworkmustonlybeperformedbyqualiedelectricians.
¾ Disconnect the power supply before installing, removing or rewiring the drum motor.
¾ Always observe the connection instructions and ensure that the power and control circuits of the motor are
correctly connected.
¾ Ensurethatmetalconveyorbeltframesaresucientlygrounded.
