General technical information
3.3 Technical data
Protection class IP66
Ambient temperature range for standard applications
1)
+5 °C to +40 °C
Ambient temperature range for low-temperature
applications
1)
-25 °C to +15 °C
Ambient temperature range for reduced drum motors +5 °C to +25 °C
Ramp times DLseries:≥1s
Installation altitude above sea level max. 1000 m
1)
For ambient temperatures below +1 °C, Interroll recommends anti-condensation heating and special cables or
plastic terminal boxes.
3.4 Product identication
Theserialnumberissucienttoidentifyadrummotor.Asanalternative,theinformationlistedbelowisrequired.The
valuesforaspecicdrummotorcanbeenteredinthelastcolumn.
Information Possible value Own value
Type plate of drum motor Motor type and design:
Circumferential speed v
N
:
Diameter of tube ø:
FW drum width:
Number of poles n
p
:
Rated power P
N
:
Drum design (tube design) e.g. Drum material
Coatingtype(color,material,prole,grooves)
End cover Material
Features deviating from the standard
Shafts Material
Features deviating from the standard
