User’s Manual of netMod Network Termination Unit
U-line Connection
netMod is equipped with an RJ-11 (located in the bottom side) jack to connect the U-line
(see Figure 7), with the following connection points (see bottom of netMod).
Pin Description
1 not connected
2 not connected
3 Ua
4 Ub
5 not connected
6 not connected
Figure 7: U-line connector
1
6
