Invacare G50 - 7.5 Replacing the headlights

Invacare
®
- G50
SERVICE INSTRUCTIONS
37
7.5 Replacing the headlights
Requirements:
• 6 mm Allen key
• Diagonal-nosed cutting pliers
• Cable ties
• Phillips screwdriver
Note
Please keep small parts such as screws and grommets safe during dismantling. Lay all small
parts down in such a way that they can be re-fitted in the correct order.
7.5.1 Placing seat in service position
• Use the Allen key 6 mm to loosen the screws (1)
on both sides and remove.
The seat release button is to be found at the front
underneath the edge of the seat (2).
CAUTION!
Damage to the wheelchair due to careless tipping of seat!
• When tipping the seat, make sure the fixation brackets of the backrest do not damage the
side or rear cowlings!
