SERVICE INSTRUCTIONS
Invacare
®
- G50
80
Pre-requisites:
• 11 mm spanner
• 6 mm Allen key
7.13.1 Tilting the seating system forward
• Use the Allen key to loosen the screws (1) on
both sides and remove.
The seat release button is to be found at the front
underneath the edge of the seat (2).
CAUTION!
Damage to the wheelchair due to careless tipping of seat!
• When tipping the seat, make sure the fixation brackets of the backrest do not damage the
side or rear cowlings!
