Invacare G50 - 7.11.2 Disassembly

SERVICE INSTRUCTIONS
Invacare
®
- G50
72
7.11.2 Disassembly
Removing the swing-away legrests
• Press the unlocking button (1) and swivel the footrest
outward.
• Remove the footrest in an upward direction.
Removing the fixed legrests
• Loosen the fixation screw with open-end
spanner 13 mm.
• Pull legrest out toward the front.
• Pull the plug (1) of the bus cable out of the
remote.
