SERVICE INSTRUCTIONS
47
• Tighten the fixation bolts (2) of the drive unit with the
Allen key 8 mm and socket spanner 17 mm.
• Further assembly of the motor is carried out in reverse order to disassembly.
• Secure the motor cable using a new cable tie.
• Make sure that the fixation nuts of the drive wheels are completely tightened!
• Adjust the brake (see chapter "
Replacing the Bowden cable of the hand brake /
adjusting the brake
" on page 59)!
• Perform a test-drive.
