Inventec B800 - Page 22

5
4
Fan connectors (J114, J115, J116, J117, J118, J119)
[J115,J117,J119 are optional]
5
DIMM slots (J1, J2, J3, J4)
6
Fan connector (J113) [Optional]
7
Fan connector (J112)
8
CPU 0 (U4)
9
DIMM slots (J5, J6, J7, J8)
10
P12VA Power connector (J88)
11
SATA connectors (J40, J41, J42, J43, J44, J45)
12
FAN connectors (J107, J108, J109, J110, J111)
[J107,J109,J111 are optional]
13
SGPIO connector (J46)
14
FAN connector (J106)
15
Mini SAS connector (J105) [for 10Gbe with
Patsburg–D SKU]
16
Intruder Header (J53)
17
Mini SAS connector (J104)
18
BIOS recovery Jumper (J22)
19
Thermal sensor BP connector (J59)
20
Front Panel connector (J90)
21
P12VB power connector (J20)
22
Front USB Connector (J17)
23
CMOS Clear Jumper (J52)
24
Password Clear Jumper (J49)
25
PCI-E Slot 2 X 8 (J80)
26
Battery (BH2)
27
SFP Connector + Cage 1 (J28+J31) [Optional for
10Gbe SKU]
28
10G NIC2 LINK/ACT AND SPEED LED (CR15)
[Optional for 10Gbe SKU]
29
SFP Connector + Cage 2 (J29+J30) [for 10Gbe SKU]
30
10G NIC1 LINK/ACT AND SPEED LED (CR16) [for
10Gbe SKU]
