Hardware Operations
16
2.4.1 To remove the heat sink
Loosen four securing screws.
Lift the heat sink up from the installed processor.
Figure 2-3 Remove Heat Sink
2.4.2 To install the heat sink
Reverse the steps above to install the heat sink.
Before you put the heat sink on top of the installed processor, please do not forget
to check if the grease is complete on bottom of the heat sink.
