3.8 Front Panel Connector (J90)
Figure 3-8 Front Panel Connector
Table 3-28 Pin Definition of Front Panel Connector (J90)
Signal Name
Pin
Pin
Signal Name
P3V3_STBY
1
2
P3V3_STBY
4
P5V_STBY
LED_PWR_GRN_N
5
6
BMC_UID_LED_R_N
P3V3
7
8
FP_HLTH_GRN_LED_N
LED_HDD_ACT_R_N
9
10
FP_HLTH_RED_LED_N
BTN_FP_PWR_N
11
12
P3V3_STBY
Ground
13
14
LED_NIC1_LINK_ACT_R_N
BTN_FP_RST_N
15
16
I2C_SDA_SENS_FP_BUF
Ground
17
18
I2C_SCL_SENS_FP_BUF
BTN_UID_N
19
20
INTRUDER_N
LED_PWR_AMBER_R_N
21
22
P3V3_STBY
BTN_FP_NMI_N
23
24
LED_NIC2_LINK_ACT_R_N
