48
Signal Name
Pin
Pin
Signal Name
Ground
B36
A41
Ground
Ground
B39
A42
Ground
Ground
B40
A45
Ground
Ground
B43
A46
Ground
Ground
B44
A49
Ground
Ground
B49
A51
Ground
Ground
B52
A54
Ground
Ground
B53
A55
Ground
Ground
B56
A58
Ground
Ground
B57
A59
Ground
Ground
B60
A62
Ground
Ground
B61
A63
Ground
Ground
B64
A66
Ground
Ground
B65
A67
Ground
Ground
B68
A70
Ground
Ground
B69
A71
Ground
Ground
B72
A74
Ground
Ground
B73
A75
Ground
Ground
B76
A78
Ground
Ground
B77
A79
Ground
Ground
B80
A82
Ground
3.10.2 PCI-Ex8 Slot (J80)
Figure 3-11 PCI-Ex8 Slot
Table 3-31 Pin Definition of PCI-Ex8 Slot (J80)
Signal Name
Pin
Pin
Signal Name
